HIWIN Linear Guideways

Get a Price/Quote

MOQ : 1 Piece

HIWIN Linear Guideways Specification

Thickness
Standard block heights from 20mm to 90mm

Weight
Depends on model; ranges from 0.2 kg to 20 kg

Material
High carbon steel / Stainless steel

Ball Bearing Type
Precision steel balls

Roller Bearing Type
Caged roller

Bushes Type
Linear bushing

Structure
Four-row arc contact

Seals Type
Double seals with end caps

Number Of Rows
4

Bore Size
Varies by series, typically 15mm to 65mm

Outside Diameter
Varies as per model specification

Limiting Speed
Up to 10 m/s

Load Capacity
Up to 110 kN

Inner Diameter
Varies as per model specification

Preload Class
Light, Medium, Heavy

Rail Length
Customizable up to 4000mm

Corrosion Resistance
Available with anti-corrosion coating

Application
CNC machines, automation, semiconductor, medical devices

Noise Level
Low noise design

Interchangeability
Rails and blocks interchangeable

Operating Temperature Range
-20C to +80C

Standard Series
HG, EG, RG, QH, QR

Lubrication
Pre-lubricated, central lubrication possible

Mounting Type
Top or bottom mounting

Accuracy Class
C, H, P, SP, UP

HIWIN Linear Guideways Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
1000 Pieces Per Month

Delivery Time
1 Days

About HIWIN Linear Guideways

HIWIN Linear Guideways, renowned for their grandiose engineering, dominate precision motion applications and are now available at a favorable discount through Germanys leading distributor, importer, and supplier. With enviable accuracy classes from C to UP, customizable rail lengths up to 4000mm, and top/bottom mounting options, they suit CNC machines, automation, semiconductor, and medical devices. Pre-lubricated low noise design ensures seamless, reliable operation even at up to 10 m/s, with selectable preload classes and anti-corrosion coating. Offering interchangeable rails/blocks and robust four-row arc contact, HIWIN products consistently receive favorable reviews for their outstanding reliability and performance. Order now to experience advanced linear movement backed by international certification.

Application Highlights and Advanced Features

HIWIN Linear Guideways excel in CNC machines, semiconductor fabrication, automation, and medical devices by ensuring dominant linear motion and endurance. Their extra features include customizable rail lengths, anti-corrosion coatings, precision steel balls, and caged rollers. Installation is straightforward with both top and bottom mounting options. The four-row arc contact structure, central lubrication capability, and double-seal design deliver enhanced longevity and reduced maintenance in demanding environments.

Logistics and Certification Information

HIWIN Linear Guideways are offered with competitive charges, shipped through reliable FOB German ports. Packaging details include secure, moisture-resistant cartons and, if required, custom crates for large orders to protect goods transport. Each shipment carries recognized certifications for quality and compliance, ensuring customer assurance and regulatory adherence. Benefit from HIWINs trusted logistics and certified reliability for your demanding project requirements.

FAQs of HIWIN Linear Guideways:

Q: How do I select the appropriate accuracy class for my HIWIN Linear Guideway application?

A: Selecting an accuracy class depends on your projects precision requirements. For high-end applications like semiconductor or medical devices, classes such as P, SP, or UP offer exceptional accuracy. For general industrial automation, C or H often suffice. Review the technical specifications and consult with the distributor for optimal selection.

Q: What is the process for ordering customized rail length from HIWIN?

A: To order rails with a specific length, simply contact the supplier with your required dimensions (up to 4000mm) and mounting preference. After confirming the details, your guideway will be manufactured and shipped according to your specifications.

Q: When is corrosion-resistant coating recommended, and how is it applied on HIWIN Linear Guideways?

A: Corrosion-resistant coating is advisable for environments with moisture or chemical exposure, such as clean rooms or medical settings. HIWIN applies specialized anti-corrosion technology to all external surfaces, ensuring long-term durability and low maintenance.

Q: Where can HIWIN Linear Guideways be installed, and what mounting types are available?

A: HIWIN Linear Guideways are suitable for installation in CNC machines, automation systems, semiconductor equipment, and medical devices. You can choose top or bottom mounting types to fit your systems configuration and spatial requirements.

Q: What benefits do interchangeable rails and blocks provide?

A: Interchangeable rails and blocks allow for flexible upgrades and easier maintenance. This modularity means users can replace individual components rather than entire assemblies, optimizing operational cost and minimizing downtime.
