MINDMAN MCSS series

Get a Price/Quote

MOQ : 1 Piece

MINDMAN MCSS series Specification

Size
Bore Size: 25, 32, 40 mm

Shape
Rectangular

Weight
Varies with stroke; approx. 2-6 kg

Hardness
HV 200-250

Accuracy
High Precision

Thread Type
Metric Thread

Coating
Anodized Coating

Machine Type
Pneumatic Automation

Method
Pneumatic Drive

Load Capacity
Up to 60 kg (depends on bore/stroke)

Type
Rodless Cylinder

Material
Aluminium Alloy

Tolerance
0.02 mm

Surface
Smooth / Anodized

Use
Industrial Automation

Application
Linear Motion / Automation Equipment

Usage & Applications
Actuation for sliding and pushing mechanisms

Maximum Stroke
Up to 1500 mm

Lubrication
Not required (oil-less operation)

Operating Pressure
0.15-0.7 MPa

Port Size
Rc 1/8" or Rc 1/4" (according to model)

Speed Range
50 to 1000 mm/sec

Operating Temperature Range
-10C to 60C

Actuation
Magnetically Coupled Slider

Piston Seal Material
NBR

Mounting
Multiple mounting options (bottom, side, foot bracket)

Cushion Type
Bumper at Both Ends

Repeatability
0.1 mm

Order Code
MCSS-25/32/40 (model dependent)

Dust Protection
Optional dust band available

Sensor Mounting Slot
Integrated for reed/proximity sensors

About MINDMAN MCSS series

Utilise the highlighted offer on the MINDMAN MCSS Seriesan unprecedented rodless cylinder solution for accurate linear motion in industrial automation. Designed with a magnetically coupled slider, this popular series achieves strokes up to 1500 mm, with stellar repeatability at 0.1 mm. Its oil-less, maintenance-free operation and integrated sensor slot ensure phenomenal performance. Multiple mounting options and optional dust protection enhance usability, while precise anodized aluminium construction suits demanding environments. Available in bore sizes 25, 32, and 40 mm, the MCSS Series promises robust, reliable actuation for sliding and pushing applications.

Extensively Used for Diverse Automation Needs

The MINDMAN MCSS Series is widely adopted by manufacturers, system integrators, and industrial automation specialists. Its primary area of application is linear motion tasks in CNC systems, packaging, and conveying equipment. The advantage lies in its oil-less operation, ensuring minimal maintenance, and high precision that meets rigorous quality standards. The series elevates productivity for users requiring long, smooth strokes and robust performance in a variety of challenging industrial environments.

Global Export Markets & Flexible Supply Terms

The MINDMAN MCSS Series is successfully shipped to major export markets across Asia, Europe, and the Middle East. FOB Port options include leading seaports in India for prompt international shipments. The supply ability is adaptable, meeting customer demands with competitive asking prices. Outlay considerations are balanced against the products phenomenal reliability and advanced features, making it a prime offering for distributors, importers, and suppliers seeking seamless automation integration.

FAQs of MINDMAN MCSS series:

Q: How does the MINDMAN MCSS series ensure high precision in linear motion applications?

A: The MCSS series uses a magnetically coupled slider with a repeatability of 0.1 mm and a high-precision pneumatic drive, ensuring accurate and reliable actuation for sliding and pushing mechanisms.

Q: What are the main benefits of the oil-less operation offered by the MCSS Series?

A: The oil-less operation eliminates the need for lubrication, reducing maintenance costs and downtime while maintaining smooth, consistent performance even in demanding applications.

Q: Where can the MCSS Series be commonly installed or employed?

A: This series is often used in industrial automation environments such as CNC machinery, packaging lines, and conveyor systems, especially where clean, precise, and maintenance-free operation is required.

Q: What is the process for mounting the MCSS rodless cylinder in different setups?

A: The MCSS Series offers multiple mounting options, including bottom, side, and foot bracket types, making it adaptable to various installation requirements and machinery layouts.

Q: How does the optional dust band enhance the performance of the MCSS Series?

A: The optional dust band provides additional protection in dusty or particle-laden environments, prolonging the life of the unit and ensuring more reliable actuation under challenging conditions.

Q: When is it recommended to utilise a larger bore size in MCSS Series applications?

A: A larger bore size is most beneficial when higher loads or extended strokes are involved, as this provides greater load capacity and durability for demanding automation needs.
